MEL1-125 Miniature Circuit Breakers with 6kA breaking capacity was designed to provide protection against short circuit and overload for domestic,commercial and industrial electrical installations.
| Model No. | MEL1-125 | Rated insulation voltage | 500V |
| Standards | IEC 61008-1 (Type AC/ A) IEC 62643 (Type B) | Breaking capacity | 1kA |
| Certifications | CE, CB | Ambient temperature | -25℃~ +45℃ |
| Number of poles | 1P+N, 3P+N | Maximum humidity | 95% |
| Rated currents | 16, 20,25, 32,40 ,63,80A | Degree of protection | IP20, with connected conductors |
| Rated voltate | 1P+N(230V),3P+N(400V) | Terminal tightening torque | 3.5 N • m |
